A real mountain bike to fuel the imagination.
Take their love for riding to the next level on the all new Bandit.
Kids are progressing faster and younger than ever, so we designed the Bandit with geometry that provides stability and confidence, while being intuitive and easy to ride. With 20” wheels, a 100mm travel fork, and a carefully selected mix of youth-specific components, we've ensured that everything on this bike is tailored to give the rider a bike that truly fits their size, weight, and use. The result is an accessible yet high-performance bike that both kids and parents will be excited about.
| Frame | Bandit Alloy |
| Wheel Size | 20" |
| Fork | Manitou Junit Sport (100mm) |
| Headset | FSA No.57E |
| Stem | Trans-X (35mm) |
| Handlebar | SDG Slater JR (600 x 19mm) |
| Grips | SDG Slater JR |
| Saddle | SDG Fly JR |
| Seatpost | Trans-X SP66 |
| Brakes | Shimano MT410 Short Reach |
| Rotors | Shimano RT56 (160mm) |
| Shifter | Shimano Cues SL-U4050 Short Reach (9sp) |
| Derailleur | Shimano Cues RD-U4000 (9sp) |
| Cassette | Shimano CS-LG400 Linkglide (11-36T) |
| Chain | Shimano CN-LG500 Linkglide |
| Crank | Samox 2 Piece Alloy (Direct Mount 28T / 135mm) |
| Rims | WTB ST i30 |
| Spokes | Pillar Straight Gauge |
| Hubs | Sealed Bearing (12 x 148mm Rear / 15 x 110mm Front) |
| Tyre/Front | Maxxis Minion DHRII (2.3) |
| Tyre/Rear | Maxxis Minion DHRII (2.3) |
| Included | SDG Slater Jr Pedals, Fidlock Twist Bike Base |
| Color Options | Raw Alloy, TR Blue |
| Weight | 23.6 lbs / 10.70 kg (Including Pedals) |
A 20" Hardtail That's Ready To Get Rad
The intuitive geometry helps young riders of all levels progress quickly and safely.
Internal Cable Routing for the Derailleur and Brake
Keeping cables out of harm's way on bike racks and any other shenanigans kids may get up to.
Youth Specific Components
Everything on the Bandit is tailored to give the rider a bike that truly fits their size, weight and use.
-
One Size:
The 310mm reach and 457mm stack fits a range of kids from roughly 3'8" to 4'4" (113 - 132cm). -
20" Wheels:
Big enough to handle real trails but nimble and easy to manoeuvre for the young and aspiring riders. -
66° Head Tube Angle & 350mm Chainstays:
We designed the Bandit to ride well on trails, but remain easy to get acquainted with to inspire confidence. -
Youth Specific Components:
Every piece was chosen to perfectly fit the riders meant for this bike. Highlights include the 20" Manitou fork, short reach brake levers and SDG's youth specific grips, saddle and pedals. -
2.3" Maxxis DHRII Tyres with WTB Rims:
The riders may be small, but they deserve every bit of traction grown ups do! -
Available in 2 Colour Options:
Raw alloy, TR Blue. -
Waterbottle Compatible:
The Bandit fits the 450ml Fidlock water bottle. -
12 x 148mm Dropouts with UDH Hanger:
Standard dropouts and UDH hanger make it easy to get replacement parts.
Geometry
| One Size | ||
| A | REACH | 310 mm |
| B | STACK | 457 mm |
| C | EFFECTIVE TOPTUBE LENGTH | 433 mm |
| D | SEATTUBE LENGTH | 260 mm |
| E | SEATTUBE ANGLE | 75° |
| F | HEADTUBE LENGTH | 100 mm |
| G | HEADTUBE ANGLE | 66° |
| H | CHAINSTAY LENGTH | 350 mm |
| I | WHEELBASE | 905 mm |
| J | BOTTOM BRACKET DROP | 5 mm |
| K | ESTIMATED BOTTOM BRACKET HEIGHT | 255 mm |
| L | STANDOVER (LOWEST POINT) | 485 mm |
| M | STANDOVER (125mm IN FRONT OF BB) | 585 mm |
Sized for young riders
Trail-ready 20-inch platform
