Orbea
Orbea Gain M10i 2026
Orbea Gain M10i 2026
Special Order
SKU:T38702GM
files/Orbea-Gain-M10i-2026-BRINK-2.jpg
12:16 AM
Couldn't load pickup availability
2026 Orbea Gain M10i: The Ultimate Lightweight eRoad Experience
The Gain M10i represents the purest expression of Orbea’s eRoad concept. It rides like a high-end carbon road bike first, with the Mahle X20 system quietly extending your range rather than defining the ride. Light, precise and beautifully finished, this is the Gain for riders who want top-tier performance with almost invisible assistance.
With a full Dura-Ace Di2 drivetrain, carbon cockpit and carbon wheels, the M10i feels fast and responsive on climbs, smooth at speed, and completely natural on rolling terrain. The motor support fades into the background, leaving you with a bike that simply feels like a very good day on the road.
Who is it for?
Experienced road riders who want premium components, minimal weight and seamless assistance for long rides, big climbs or staying competitive in mixed-ability groups.
Highlights
-
Frame material
Carbon
-
Wheelsize
700c
-
Front travel
0mm
-
Rear travel
0mm
-
Motor brand
Mahle
-
Max torque
50Nm
-
Peak power
275W
-
Battery capacity
350Wh
Specifications
-
2026 Orbea Gain M10i
Frame
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Fork
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Handlebar
OC Road Performance RP11-R Carbon, Rise 15, Reach 70, Drop 125
Stem
OC Road Performance RP10, -8º
Headset
FSA 1-1/2" Integrated Aluminium Cup
Brakes
Shimano R9270 Hydraulic Disc
Front rotor
Shimano
Rear rotor
Shimano
Shifter
Shimano R9270
Rear derailleur
Shimano Dura-Ace Di2 R9250
Crankset
Shimano Dura-Ace R9200 34x50t
Cassette
Shimano Dura-Ace R9200 11-30t 12-Speed
Chain
Shimano CN-9100
Seatpost
OC Performance XP10-S Carbon, 27.2mm, Setback 20
Saddle
Fizik Vento Antares R1 Carbon Rail 140mm
Front hub
OEM
Rear hub
Male
Rims
Carbon 42, Tubeless, 21c
Rear rim
Carbon 42, Tubeless, 21c
Front tyre
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Rear tyre
Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
Motor
Mahle motor hub X20, ALC
Battery
Mahle iX350 36V 353Wh
Mahle X20 Motor
One of the lightest, most compact e-bike drive system on the market. 50Nm of nearly silent, frictionless assistance gives more than enough power for even the toughest climbs.
OMR Carbon
OMR frames add high modulus and high strength fibers to a standard layup to improve stiffness-to-weight ratios.
350Wh Downtube
You can pretty much forget about the battery capacity unless you plan on climbing more than 4000m.
Integrated Lighting
Gain is safer and more functional with head and tail lamps that announce your presence day and night. The built-in light sensor automatically switches Gain´s inbuilt lights on and off.
