2026 Orbea Oiz H10 – Alloy Race Bike with Fox Factory DNA
The Oiz H10 turns Orbea’s refined alloy chassis into a serious XC race tool. With Fox 34 Float SL suspension, remote lockout and a blend of Deore and XT components, it’s built for riders who want carbon-bike performance from an aluminium frame.
High-Polish Alloy Frame, Same Race Intent
Like the H30, the H10 uses Orbea’s hydroformed, high-polish aluminium frame with Boost spacing, UFO rear triangle and I-Line shock routing. The geometry is pure race: steep enough to climb efficiently, long and stable enough to attack technical descents at speed.
Fox 34 SL Performance 120 mm Suspension
The upgrade to a Fox 34 Float SL Performance fork brings extra stiffness and precision on rougher XC courses. Paired with the Fox Float SL Performance shock and twin-remote lockout, the H10 switches from fully open to sprint-ready in an instant.
Shimano Deore / XT Drivetrain Blend
A Deore shifter drives an XT rear derailleur across a wide-range 10–51T cassette, giving you crisp shifting and proven reliability. Shimano’s MT410 brakes add consistent control on long descents without complicating service or setup.
Race-Ready Tyres Out of the Box
Schwalbe Wicked Will Evo tyres in Super Race, Speed Grip spec deliver fast rolling with enough bite for modern technical XC. Mounted to 26 mm tubeless-ready rims, they’re a great match for all-weather racing and marathon events.
Who Is the Oiz H10 For?
Riders who want an aluminium Oiz that’s genuinely ready for the start line. If you’d rather put budget into suspension and tyres than into a carbon frame, the H10 hits that sweet spot.
Highlights
-
Frame material
Aluminium
-
Wheelsize
29"
-
Front travel
120mm
-
Rear travel
120mm
Specifications
-
2026 Orbea Oiz H10
Frame
Orbea Oiz Hydro High Polished, Alloy link, Boost, BSA, SIC, UFO, I-Line shoc
Fork
Fox 34 Float SL Performance 120, Grip, Remote Push to Lock, QR15x110
Shock
Fox Float SL Performance 120mm Remote Push-lock Evol custom tune 190x45mm
Handlebar
OC Mountain Performance MP30, Width 760
Stem
OC Mountain Performance MP21, -6º
Headset
Alloy 1-1/2”, Black Oxidated Bearing
Brakes
Shimano MT410 Hydraulic Disc
Front rotor
Shimano
Rear rotor
Shimano
Shifter
Shimano Deore M6100
Rear derailleur
Shimano XT M8100 SGS Shadow Plus
Crankset
Shimano MT512 32t
Bottom bracket
Shimano
Cassette
Shimano CS-M6100 10-51t 12-Speed
Chain
Shimano M6100
Seatpost
OC Mountain Control MC22, 31.6mm, Dropper
Saddle
Fortune QF-3091
Front hub
OEM
Rear hub
OEM
Spokes
OEM
Rims
Alloy, 26c, 28H, TLR
Rear rim
Alloy, 26c, 28H, TLR
Front tyre
Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Speed Grip, Addix, Brown
Rear tyre
Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Speed Grip, Addix, Brown
Race Ready Geometry
A steep seat tube and lower stack puts you in the driving seat, in full control of your ride. The longer reach, designed around a 60-90mm stem, offers stability on the descents while maintaining a weighted front wheel for attacking on the climbs and corners.
Efficient Suspension
Designed from the start around 120mm of race-tuned suspension, means Oiz offers unbeatable confidence and efficiency. Attack on the climbs and drop the competition on the descents.
Tuned Rigidity
For a bike to have the lightning reflexes and efficiency of a true XC race bike it needs to be light and stiff.
Direct Shock Lockout Routing
Our patented I-line is simply the sleekest, most direct, most integrated shock lock-out on the market. The shock lockout cable take the inside line all the way to the remote lever, meaning less cable, less dirt and less friction.
High Polish Alloy
Our high polished alloy is simply the best aluminium frame you can buy, with the bonus of that carbon-look.
